A wireless mouse refers to a mouse that is directly connected to the host without a cable, and uses wireless technology to communicate with the computer, thereby saving the shackles of wires. Usually wireless communication methods are used, including multiple wireless technology standards such as Bluetooth, Wi-Fi (IEEE 802.11), Infrared (IrDA), ZigBee (IEEE 802.15.4), etc. But in general, this kind of wireless products need to apply for CE-RED certification if they want to export to the EU.

What is CE-RED certification?

The CE (Conformite Europeenne, European Union) mark is a safety certification mark, which is regarded as a passport for manufacturers to open and enter the European market. CE-RED certification is abbreviated as Red certification (European wireless product certification), and the purpose is that wireless products entering Europe must pass this test certification.

In the EU market, the CE mark is a compulsory certification mark. All products with the CE mark can be sold in the member states of the European Union (EU CE certification), without having to meet the requirements of each member state, thus realizing the scope of the products in the EU member states Free circulation within.

Wireless mouse CE-RED certification test standard

EN 300328 (RF test)

EN 301489-17 (EMC test)

EN 60950-1: 2006 (Safety safety test)

EN 62311 (Injury Assessment)

Wireless mouse CE-RED certification test items

1. Electromagnetic compatibility test (EMC test);

2. Safety test LVD (in the new directive, this test is also required for battery input RF products);

3. Perform radio communication equipment testing (RF testing) in accordance with European ETSI standards;

4. Information notification of European permitted spectrum (Notification);

5. CTR (TBR) test;

6. Electrical safety and health protection test (SAR evaluation).

Materials to be prepared for wireless mouse CE-RED certification

1. User manual; circuit schematic diagram;

2. Circuit block diagram (BlockDiagram, also called module function diagram);

3. Circuit layout diagram (PCBLAYOUT); circuit location number diagram (PCBplacement);

4. Operation description (an explanation of the block diagram); component list (BOMLIST);

5. Label; antenna specifications (or antenna gain diagram);

6. Charger LVD report; fixed frequency software (also called fixed frequency program, so that the transmitter module can be fixed at a certain frequency point for continuous transmission, generally BT and WIFI must be provided).

Wireless mouse CE-RED certification process

1. Project application: submit an application for CE certification to the supervision of the testing agency.

2. Document preparation: According to CE certification requirements, the company prepares relevant certification documents and materials;

3. Product testing: The company sends samples to the laboratory for product testing;

4. Preparation report: The certified engineer prepares the report based on the qualified test data;

5. Submit for review: The engineer will review the complete report;

6. Certificate issuance: CE certification will be issued after the report is verified.

For wireless mouse CE-RED certification, please contact our company ZRLK. We will provide you with professional and efficient testing and certification services with favorable prices and courteous service. If you provide us with product pictures and specifications, we will give us the corresponding cycle, quotation and specific plan according to your product. Welcome to inquire!
