Projection lamps, also known as spotlights, are mainly used for large-area workplaces, mines, building outlines, stadiums, overpasses, monuments, parks and flower beds. Almost all large-area outdoor lighting fixtures can be regarded as projection lamps. But generally, if such products want to be exported to the EU market, they need to apply for CE certification.

What is CE certification?

The "CE" mark is a safety certification mark, which is regarded as a passport for manufacturers to open and enter the European market. CE stands for Conformite Europeenne. In the EU market, the "CE" mark is a mandatory certification mark. Whether products produced by enterprises within the EU or products produced in other countries, if they want to circulate freely in the EU market, they must be affixed with the "CE" mark to indicate that the products meet the basic requirements of the EU New Method for Technical Coordination and Standardization. This is a mandatory requirement of EU laws on products.

CE certification provides a unified technical specification for the products of various countries to trade in the European market and simplifies the trade procedures. The products of any country that want to enter the European Union and the European Free Trade Area must be CE certified and affixed with the CE mark. Therefore, CE certification is a passport for products to enter the markets of EU and EFTA countries.

CE certification test standard for projection lamps

LVD Electronic and Electrical Safety

EN 60598-1 General Requirements for Lamps

EMC electromagnetic compatibility test standard

1. EN 55015 Measurement Methods and Limits of Radio Interference Characteristics of Electronic Lighting and Similar Equipment

2. EN61547 Limits and Measurement Methods of Radio Immunity of Electrical Lighting and Similar Equipment

3. EN61000 Electromagnetic Compatibility (EMC)

Test items of projection lamp CE certification

◆ marking; Structure;

◆ Creepage distance and electrical clearance;

◆ Grounding continuity; Terminal blocks;

◆ Power supply wiring and internal wiring;

◆ Electric shock protection;

◆ Durability test and thermal test;

◆ Dust prevention, solid foreign matter prevention and waterproof;

◆ Insulation resistance, electrical strength, contact current and protective conductor current;

◆ Heat resistance, fire resistance and marking resistance.

Materials to be prepared for application for CE certification of projection lamps

1. Product difference table;

2. Circuit schematic diagram, copper foil wiring diagram, component silk screen diagram;

3. Dimension drawing of engineering structure;

4. Inductance and transformer specifications;

5. BOM;

6. List of key components;

7. Label and date code;

8. Installation instructions;

9. LED specifications.

CE Certification Process of Floodlight

1. Project application - submit the application to the supervision of the testing agency.

2. Data preparation: according to the standard requirements, the enterprise shall prepare relevant certification documents.

3. Product testing - the enterprise sends the samples to be tested to the laboratory for testing.

4. Preparation of report - The certification engineer shall prepare the report according to the qualified test data.

5. Submit for review - The engineer will review the complete report.

6. Issue certificate - issue the report after the report is verified to be correct.
